Fuses a piercing 2,300-lumen output and 256m distance via patented Claw Optics™. Seamlessly switch between white and night-vision red lights, delivering versatile multi-mode adaptability and an ultra-long 220-hour maximum runtime.
Magnesium Alloy Ultra-Light Airframe
Crafted from premium aerospace-grade magnesium alloy. It delivers aluminum-level ruggedness at 1/3 less weight, weighing just 96g to eliminate neck fatigue during extended tactical or outdoor missions.
Patented Claw Optics™ Dual-Beam
Empowered by NEXTORCH’s proprietary optical system. It fuses a tight spotlight and a 100° smooth floodlight into a seamless, high-efficiency hybrid beam—delivering a max 2,300 lumens and 256-meter throw.
Flexible Hybrid Power Solution
Engineered for mission continuity. It features smart power management that runs efficiently on a single high-capacity 3400mAh 18650 rechargeable battery, while maintaining full compatibility with two reliable CR123A batteries for extreme cold or backup power.
All-Weather IP67 Rugged Reliability
Built to survive the harshest environments. This heavy-duty headlamp features IP67 waterproof protection and 1-meter impact resistance, ensuring flawless performance under heavy downpours, dusty tactical operations, or rigorous outdoor training.





Specifications
| ANSI / PLATO-FL1 | Spot & Flood Light | Spotlight | Floodlight | Red Light | SOS |
|---|---|---|---|---|---|
| Light Output | 2300 ~ 20 lm | 1100 ~ 10 lm | 1100 ~ 10 lm | 55 ~ 3 lm | 55 ~ 3 lm |
| Run Time | 2h 15min ~ 95h | 4h ~ 180h | 4h ~ 180h | 10h ~ 220h | — |
| Beam Distance | 256 ~ 24 m | 250 ~ 23 m | 55 ~ 4 m | — | — |
| Beam Intensity | 16384 ~ 144 cd | 15625 ~ 132 cd | 756 ~ 4 cd | — | — |
| Impact Resistance | 1 m | ||||
| Waterproof | IP67 | ||||
| Weight & Dimensions | Weight: 126 g / 4.4 oz (Without Battery), 180 g / 6.35 oz (With Battery and Headband) Size: 82 mm (Length) × 46 mm (Width) × 35 mm (Height) |
||||
| Material | Light Source: White / Red Light LEDs Body Material: Magnesium Alloy |
||||
| Battery | One 3400mAh or two CR123A | ||||
